1492-D2C200- ALLEN BRADLEY Miniature Circuit Breakers

Allen Bradley, Molded Case , 1492-D Miniature Circuit Breakers, Trip Curve C, 2-Pole, 20 A 1492-D2C200, Allen Bradley, Bulletin 1492-D, type 1492-D, 2P, 1PH,20A, 500V DC, bolt-on, complete with non-interchangeable trip , LI - Long-Time and Instantaneous trip functions, thermal magnetic, mini molded case circuit breakers, UL listed/CSA certified.

PDF:

1492-D2C200 TECHNICAL DATA

1492-D2C200 SELECTION GUIDE

Miniature Circuit Breaker, Voltage Rating: UL/CSA: 500 VDC, EN/IEC: 440 VDC, Amperage Rating: 20 A, Interrupt Rating: 10 KA, Number Of Poles: 2, Trip Type: Type C Curve, Trip Range: 5 - 10 Times Of A, Dielectric Strength : 2000 V, Enclosure: IP20, IP40, Auxiliary Contacts: Yes, Material: Insulation Group II, RAL 7035, Length: 75 MM, Width: 35 MM, Height: 88 MM, Environmental Conditions: Storage: -40 To 70 DEG C, Shock: 25 G - 2 shocks 13 MS, Vibration: 5 G - 20 cycles at 5 - 50 - 5 HZ with load 0.8 IN, Operating Cycles: Electrical: 6000 Operation, Mechanical: 20000 Operation, Ambient: -25 To 55 DEG C, Mounting: DIN Rail, Wire Size: 18 - 10 AWG
